Step 2 Mount the upper fixture assembly on the metal pole. Ensure that the four ends of the fixture
assembly are on the same plane, as shown in

Figure 3-30 Mounting the upper fixture assembly

Figure 3-31 Holes in the fixture assembly

Step 3 Use the level bar to check whether the four ends of the fixture assembly are on the same plane.
Use the tape measure to check whether the two pole fixtures are parallel.
Issue 01 (2008-04-18)
NOTE
It is recommended that the upper fixture assembly be 1,200 mm to 1,600 mm above the ground.
NOTE
Two pairs of holes can be used for mounting the fixture assembly, as shown in
mm bolts are used, use pair 1. If the 90-114 mm bolts are used, use pair 2.
NOTE
If the difference between L1 and L2, as shown in
not parallel.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
3 Installing RRU and SRXU Hardware
Figure 3-30.
Figure 3-32, is beyond ±1 mm, the two pole fixtures are
Figure 3-31. If the 60-95
3-31
