RRU
User Guide
Pin Assignment
Table 2-13

Table 2-13 Pin assignment for the wires of the DC power cable

X1 End
X1.6
X1.7
Installation Position
One end of the DC power cable is connected to the RET/PWR_SRXU port at the bottom of the
RRU, and the other end is connected to the PWR_SRXU socket at the bottom of the SRXU.

2.4.3 AISG Multi-Wire Cable of the RRU/SRXU

The five-meter-long AISG multi-wire cable connects the RRU/SRXU to the Remote Control
Unit (RCU). If both RRU and SRXU are installed, the AISG multi-wire cable only connects the
SRXU and the RCU. This cable is optional.
Appearance
The cable has a waterproof DB9 connector at one end and a standard AISG female connector at
the other end, as shown in

Figure 2-17 AISG multi-wire cable

Pin Assignment
Table 2-14
Issue 01 (2008-04-18)
describes the pin assignment for the wires of the DC power cable.
X2 End
X2.6
X2.7
Figure 2-17.
describes the pin assignment for the wires of the AISG multi-wire cable.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
Wire Color Wire Type
White and blue Twisted pair
Blue
White and Twisted pair
orange
Orange
2 RRU and SRXU Hardware
Remarks
DC Power
Cable
GND
2-21
