3 Installing RRU and SRXU Hardware
2.
Step 2 Drill a hole at each anchor point and install the expansion bolt assembly, as shown in
3-40.
3-36

Figure 3-38 Installed expansion bolt assemblies and the RRU

NOTE
It is recommended that the bottom of the mounting plate be 1,200 mm to 1,600 mm above the ground.
Place the mounting plate against the wall, and then use the marking pen to mark the four
anchor points. You can also mark four points according to the inter-hole distance, as shown
in Figure 3-39.

Figure 3-39 Determining the anchor points

Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
RRU
User Guide
Figure
Issue 01 (2008-04-18)
