Board Setup and Configuration
Electrostatic Discharge Caution
ESD can damage electronic components when they are improperly handled, and can result
CAUTION!
in total or intermittent failures. Always follow ESD-prevention procedures when removing and
replacing components.
To prevent ESD damage:
•
Use an ESD wrist or ankle strap and ensure that it makes skin contact. Connect the
equipment end of the strap to an unpainted metal surface on the chassis.
•
Avoid touching the adapter against your clothing. The wrist strap protects components
from ESD on the body only.
•
Handle the adapter by its bracket or edges only. Avoid touching the printed circuit
board or the connectors.
•
Put the adapter down only on an antistatic surface such as the bag supplied in your kit.
•
If you are returning the adapter to Xilinx Product Support, place it back in its antistatic
bag immediately.
Board Component Location
Figure 2-1
shows the KCU116 board component locations. Each numbered component
shown in the figure is keyed to
the respective schematic page numbers, and links to a detailed functional description of the
components and board features in
Figure 2-1
IMPORTANT:
board.
The KCU116 board can be damaged by electrostatic discharge (ESD). Follow standard ESD
CAUTION!
prevention measures when handling the board.
KCU116 Board User Guide
UG1239 (v1.2) September 28, 2018
Table
2-1.
Table 2-1
Chapter
3.
is for visual reference only and might not reflect the current revision of the
www.xilinx.com
identifies the components, references
Send Feedback
Chapter 2
9
