Board Setup and Configuration

Electrostatic Discharge Caution

CAUTION! ESD can damage electronic components when they are improperly handled, and can result in total or
intermittent failures. Always follow ESD-prevention procedures when removing and replacing components.
To prevent ESD damage:
• Use an ESD wrist or ankle strap and ensure that it makes skin contact. Connect the equipment
end of the strap to an unpainted metal surface on the chassis.
• Avoid touching the adapter against your clothing. The wrist strap protects components from
ESD on the body only.
• Handle the adapter by its bracket or edges only. Avoid touching the printed circuit board or
the connectors.
• Put the adapter down only on an antistatic surface such as the bag supplied in your kit.
• If you are returning the adapter to Xilinx
immediately.

Board Components

The following figure shows the SP701 board component locations. Each numbered component is
keyed to the table in
IMPORTANT! The following figure is for visual reference only and might not reflect the current revision of the
board. There could be multiple revisions of this board. The specific details concerning the differences between
revisions are not captured in this document. This document is not intended to be a reference design guide and the
information herein should not be used as such. Always refer to the schematic, layout, and XDC files of the specific
SP701 version of interest for such details.
UG1319 (v1.0) July 12, 2019
SP701 Board User Guide
®
Board Component Location.
Product Support, place it back in its antistatic bag
