Configuration
For public disclosure
5.3.3 Configurable Memory for CPU Module
IC200CPUE05
Configurable memory
Application program size (not configurable)
Hardware configuration size (not configurable)
Registers (%R)
Analog Inputs (%AI)
Analog Outputs (%AQ)
If you reconfigure memory allocation from the default sizes, storing a hardware
configuration to the PLC in the future will clear memory contents. If you want to retain
memory contents, first load memory contents from the PLC to the programmer. Then,
re-store memory when you store the hardware configuration from the programmer to the
PLC.
128K bytes maximum
128 bytes minimum
528 bytes minimum
256 bytes (128 words) minimum
256 bytes (128 words) minimum
256 bytes (128 words) minimum
GFK-1503E User Manual 75
