ACS550 User's Manual

Analog Cables

Recommendations for analog signal runs:
• Use double shielded, twisted pair cable.
• Use one individually shielded pair for each signal.
• Do not use a common return for different analog signals.

Digital Cables

Recommendation for digital signal runs: A double shielded cable is the best
alternative, but single-shielded, twisted, multi-pair cable is also usable.
Control Panel Cable
If the control panel is connected to the drive with a cable, use only Category 5 Patch
ethernet cable. The maximum length that is tested to meet EMC specifications is 3 m
(9.8 ft). Longer cables are susceptible to electromagnetic noise and must be user-
tested to verify that EMC requirements are met. Where long runs are required
(especially for runs longer than about 12 m (40 ft)), use a RS232/RS485 converter at
each end and run RS485 cable.
Drive's Control Connection Terminals
The following table provides specifications for the drive's control terminals
Frame Size
All

Efficiency

Approximately 98% at nominal power level.

Cooling

Method
Requirement
Air Flow, 208...240 Volt Drives
The following table lists heat loss and air flow data for 208...240 Volt drives.
ACS550-x1-
-04A6-2
-06A6-2
Maximum Wire Size
2
mm AWG
1.5 16
Internal fan, flow direction from bottom to top.
Free space above and below the ACS550 drive: 200 mm (8 in).
Free space is not required on the drive's sides – ACS550 units can be mounted side-
by-side.
Drive
Frame Size
R1 55
R1 73
Control
Torque
Nm lb-ft
0.4 0.3
Cooling Specifications
Heat Loss
W BTU/Hr
189
249
Air Flow
3 3
m /h ft /min
44 26
44 26
Technical Data
235
