ACS550 User's Manual
Fault
Code
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Fault Name In
Panel
Possible ground fault detected in the motor or motor cables. The drive
EARTH FAULT
monitors for ground faults while the drive is running and while the drive is
not running. Detection is more sensitive when the drive is not running and
can produce false positives.
Possible corrections:
• Check for/correct faults in the input wiring.
• Verify that motor cable does not exceed maximum specified length.
• A delta grounded input power supply and motor cables with high
capacitance may result in erroneous error reports during non-running
tests. To disable response to fault monitoring when the drive is not
running, use parameter 3023
ground fault monitoring, use parameter 3017
Motor load is lower than expected. Check for and correct:
UNDERLOAD
• Disconnected load.
• Parameters 3013
Internal fault. The thermistor measuring the internal temperature of the
THERM FAIL
drive is open or shorted. Contact your local ABB sales representative.
Internal fault. A communication-related problem has been detected on the
OPEX LINK
fiber optic link between the OITF and OINT boards. Contact your local ABB
sales representative.
Internal fault. Low voltage condition detected on OINT power supply.
OPEX PWR
Contact your local ABB sales representative.
Internal fault. Current measurement is out of range. Contact your local ABB
CURR MEAS
sales representative.
Ripple voltage in the DC link is too high. Check for and correct:
SUPPLY PHASE
• Missing mains phase.
• Blown fuse.
If this error code appears, refer to the appropriate accessory manual.
Motor speed is greater than 120% of the larger (in magnitude) of 2001
OVERSPEED
MINIMUM SPEED
• Parameter settings for 2001 and 2002.
• Adequacy of motor braking torque.
• Applicability of torque control.
• Brake chopper and resistor.
R Not used.
ESERVED
Internal fault. Configuration Block Drive ID is not valid. Contact your local
DRIVE ID
ABB sales representative.
Internal configuration file has an error. Contact your local ABB sales
CONFIG FILE
representative.
1 Fieldbus communication has timed out. Check for and correct:
SERIAL ERR
• Fault setup (3018
• Communication settings (Group 51 or 53 as appropriate).
• Poor connections and/or noise on line.
Error in reading the configuration file for the embedded fieldbus.
EFB CONFIG
FILE
Fault trip forced by the fieldbus. See the fieldbus User's Manual.
FORCE TRIP
Description and Recommended Corrective Action
WIRING FAULT
UNDERLOAD FUNCTION
or 2002
MAXIMUM SPEED
COMM FAULT FUNC
. To disable response to all
.
EARTH FAULT
...3015
UNDERLOAD CURVE
. Check for and correct:
and 3019
COMM FAULT TIME
Diagnostics
