ACS550 User's Manual
DCU Profile
The following tables describe the
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
DCU Profile
Name Value
READY 1
0
ENABLED 1
0
STARTED 1
0
RUNNING 1
0
ZERO_SPEED 1
0
ACCELERATE 1
0
DECELERATE 1
0
AT_SETPOINT 1
0
LIMIT 1
0
SUPERVISION 1
0
REV_REF 1
0
REV_ACT 1
0
PANEL_LOCAL 1
0
FIELDBUS_LOCAL 1
0
EXT2_ACT 1
0
FAULT 1
0
content for the DCU profile.
STATUS WORD
(See Parameter 0303)
STATUS WORD
Drive is ready to receive start command.
Drive is not ready.
External run enable signal received.
No external run enable signal received.
Drive has received start command.
Drive has not received start command.
Drive is modulating.
Drive is not modulating.
Drive is at zero speed.
Drive has not reached zero speed.
Drive is accelerating.
Drive is not accelerating.
Drive is decelerating.
Drive is not decelerating.
Drive is at setpoint.
Drive has not reached setpoint.
Operation is limited by Group 20 settings.
Operation is within Group 20 settings.
A supervised parameter (Group 32) is outside its limits.
All supervised parameters are within limits.
Drive reference is in reverse direction.
Drive reference is in forward direction.
Drive is running in reverse direction.
Drive is running in forward direction.
Control is in control panel (or PC tool) local mode.
Control is not in control panel local mode.
Control is in fieldbus local mode (steals control panel local).
Control is not in fieldbus local mode.
Control is in EXT2 mode.
Control is in EXT1 mode.
Drive is in a fault state.
Drive is not in a fault state.
Status
Embedded Fieldbus
