ACS550 User's Manual
Fuses, 208...240 Volt Drives
ACS550-x1-
see below
-04A6-2
-06A6-2
-07A5-2
-012A-2
-017A-2
-024A-2
-031A-2
-046A-2
-059A-2
-075A-2
-088A-2
-114A-2
-143A-2
-178A-2
-221A-2
-248A-2
Fuses, 380...480 Volt Drives
ACS550-x1-
see below
-03A3-4
-04A1-4
-05A4-4
-06A9-4
-08A8-4
-012A-4
-015A-4
-023A-4
-031A-4
-038A-4
-044A-4
-059A-4
-072A-4
-077A-4
-096A-4
-124A-4
-157A-4
-180A-4
-195A-4
Input Current
A
IEC269 gG (A)
4.6 10
6.6
7.5
11.8 16
16.7 25
24.2
30.8 40
46.2 63
59.4
74.8 80
88.0 100
114 125
143 200
178 250
221 315
248
Input Current
A
IEC269 gG (A)
3.3 10
4.1
5.4
6.9
8.8
11.9 16
15.4
23 25
31 35
38 50
44
59 63
72 80
77
96 125
124 160
157 200
180 250
195 250
Mains Fuses
UL Class T (A) Bussmann Type
10 JJS-10
15 JJS-15
25 JJS-25
30 JJS-30
40 JJS-40
60 JJS-60
80 JJS-80
100 JJS-100
110 JJS-110
150 JJS-150
200 JJS-200
250 JJS-250
300 JJS-300
350 JJS-350
Mains Fuses
UL Class T (A) Bussmann Type
10 JJS-10
15 JJS-15
20 JJS-20
30 JJS-30
40 JJS-40
50 JJS-50
60 JJS-60
80 JJS-80
90 JJS-90
100 JJS-100
125 JJS-125
175 JJS-175
200 JJS-200
250 JJS-250
250 JJS-250
