General Information
To the control panel, the 7847i/7847i-E Internet/Intranet Communication Modules, when in ECP Mode, is
treated as a long-range radio device.
The 7847i/7847i-E can be configured to deliver alarms via the Internet to an AlarmNet
central station or via a Private LAN (7847i-E only) directly to a 7810iR-ent
methods of communication are encrypted to ensure security. The 7847i and 7847i-E use 256-
bit AES (Rijndael) encryption (which is required for certain government installations).
The 7847i/7847i-E modules require an AlarmNet–i account, except when Private LAN is enabled on
the 7847i-E. Obtain the account information from the central station prior to programming this module.
You can program a 7847i/7847i-E by one of the following methods:
•
Through the AlarmNet Direct website
•
Through use of a 7720P Programming Tool
•
Through a programming mode in control panel, on panels that support this option (e.g., Vista-
128BP and FBP)
Using the AlarmNet Direct Website
To program the module via the website (if you are already signed up for this service), go to:
https://services.alarmnet.com/AlarmNetDirect/userlogin.aspx.
If you are not signed up for this service, click on "Dealer Sign-Up".
Log in and follow the on-screen prompts.
Please have the following information available when programming the module:
1. Primary City ID (two-digit hexadecimal number)
2. Primary Central Station ID (two-digit number)
3. Primary Subscriber ID (four-digit number)
4. MAC ID and MAC CRC number (located on the outside of box and on label inside
module)
After programming is complete, you must transfer the data to the module and the module
must be registered. Refer to Section 4: Registration, for further instructions.
Using a 7720P Programming Tool
Connect the 7720P Programming Tool; refer to Figure 8 in Section 2. The 7847i and 7847i-E
power the 7720P Programming Tool via the programming jack, and automatically senses the
presence of the 7720P when it is plugged in.
Programming the 7847i/7847i-E
o
o
Alternative Mode Programming
Exiting Programming Mode
S E C T I O N
receiver.
3
Both
3-1
