Canon imagePRESS Server G200 Service Manual page 30

the cooling assembly from the CPU socket (see
and a heatsink.
NOTE:
Do not remove the CPU fan from the heatsink.
1
2
3
4
5
No.
1 CPU fan
2 Heatsink
3 CPU
■ To remove a CPU
1. Access and open the imagePRESS Server, as described on
2. Remove the motherboard components (see
3. Remove the motherboard from the chassis (see
Place the motherboard on a flat, antistatic surface.
4. Remove the CPU fan cable from motherboard connector CPU FAN.
"To remove a CPU" on page
CPU cooling assembly
ITem
"To replace motherboard components" on page
"To remove the motherboard" on page
25). The CPU cooling assembly consists of a fan
No.
4 Load plate
5 CPU socket on motherboard
6 Socket lever
"Accessing the imagePRESS Server" on page
25
3. REPLACING PARTS
6
ITem
13.
24).
21).
