3. Carefully push the clip away from the battery until the socket ejects the battery.
No.
1 Clip
2 Battery
3 Socket
4. Slide the battery out of its socket.
5. Wait two minutes to allow the motherboard electrical components to fully discharge.
6. To insert a new battery, slide it into the socket so that the positive (+) side of the battery faces front.
7. Press the battery down into the socket until it snaps into place.
Make sure that the battery is securely installed in the socket.
8. Reassemble the imagePRESS Server and verify functionality
on page 34)
9. Configure the date and time in Setup (see
● To configure the system date and time
1. On a client computer that is connected to the same network as the imagePRESS Server, open a Web browser window.
2. In the URL field of the browser, type the IP address or DNS name of the imagePRESS Server, and press Enter.
The IP address is listed under the Network Setup section of the imagePRESS Server Configuration page.
3. On the WebTools home page, click the Configure tab.
4. Type the administrator account in User name and the corresponding password in Password, then click Log In.
You can enter "Administrator" or "admin" for the administrator account name. The default password is Fiery.1 (case-sensitive).
However, the site administrator may have configured a new password for the imagePRESS Server.
5. Select Fiery Server > Regional Settings and specify the current date and time, and click Save.
6. Click Log Out to exit Configure.
■ Motherboard jumpers
IMPORTANT:
Jumper configuration should not be changed.
Jumper
J17
Pin 1
Motherboard battery
"To configure the system date and time" on page
J17 is the Clear CMOS and Password jumper. Default configuration: jumper cap installed on pins 2
and 3.
NOTE:
Because the jumper cap is very small, it is not necessary—and could introduce an error—to
remove the jumper cap in order to clear the CMOS settings.
1
2
3
Item
(see"Restoring imagePRESS Server functionality after service"
Description
19
