Table of contents Introduction
• Dynamic Host Configuration Protocol (DHCP)
• IEEE 802.1x network authentication
• IEEE 802.1q VLAN
• IEEE 802.1p QoS and class of service
• ClearPath
IPv6 network support
• Single call stack support for both H.323 and
SIP
• Dual-stack IPv4 and IPv6 for DHCP, SSH,
HTTP, HTTPS, DNS and DiffServ
• Support for both static and autoconfiguration
(stateless address autoconfiguration)
Cisco unified communications manager
(requires Cisco UCM version 8.6 or later)
• Native registration with Cisco Unified
Communications Manager
• Basic Cisco Unified Communications
Manager provisioning
• Firmware upgrade from Cisco Unified
Communications Manager
• Cisco Discovery Protocol and DHCP option
150 support
• Basic telephony features such as hold,
resume, transfer, and corporate directory
lookup
Security features
• Management using HTTPS and SSH
• IP administration password
• Menu administration password
• Disable IP services
• Network settings protection
Network interfaces
• One LAN and Ethernet (RJ-45)
10/100/1000 Mbps
Other interfaces
• Two USB host for future use
D14908.01 SX20 Administrator Guide (TC5.1) | 2012 FEBRUARY | © 2012 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings
PrecisionHD 1080p 12x camera
• 1/3" CMOS
• 12 × zoom
• +15°/-25° tilt
• +/- 90° pan
• 43.5° vertical field of view
• 72° horizontal field of view
• Focus distance 0.3 m – infinity
• 1920 × 1080 pixels progressive at 60 fps
• Other formats supported (configurable
through Dip-switch): 1920 × 1080@60
fps (HDMI only), 1920 × 1080@50 fps
(HDMI only), 1920 × 1080@30 fps, 1920 ×
1080@25 fps, 1280 × 720@60 fps, 1280 ×
720@50 fps, 1280 × 720@30 fps, 1280 ×
720@25 fps
• Automatic or manual focus / brightness /
white balance
• Far-end camera control
• Dual HDMI and HD-SDI output
• Upside-down mounting with automatic
flipping of picture
PrecisionHD camera 1080p 4xS2
• 1/3" CMOS
• 4 × zoom
• +15°/-25° tilt
• +/- 90° pan
• 43.5° vertical field of view
• 70° horizontal field of view
• Focus distance 0.3 m – infinity
• 1920 × 1080 pixels progressive at 60 fps
• Automatic or manual focus / brightness /
white balance
• Far-end camera control
• Upside-down mounting with manual flipping
of picture
Appendices Appendices
System management
• Support for the Cisco TelePresence
Management Suite
• Total management using embedded SNMP,
Telnet, SSH, XML and SOAP
• Remote software upload using web server,
SCP, HTTP and HTTPS
Directory services
• Support for local directories (My Contacts)
• Corporate directory
• Unlimited entries using server directory
supporting Lightweight Directory Access
Protocol (LDAP) and H.350 (available with
Cisco TelePresence Management Suite)
• Unlimited number for corporate directory
(available with Cisco TelePresence
Management Suite)
• Received calls with date and time
• Placed calls with date and time
• Missed calls with date and time
User interface
• Remote control and on-screen menu
• Cisco TelePresence Touch (optional)
76
Power
• Autosensing power supply
• 100 – 240 VAC, 50/60 Hz
• Maximum 40 watts for codec and main
camera
Temperature range
Operating temperature and humidity:
• Ambient temperature: 32°F to 95°F
(0°C to 35°C)
• Relative humidity (RH): 10% to 90%
Storage and transport temperature:
• –4°F to 140°F (–20°C to 60°C) at RH 10%
to 90% (non-condensing)
SX20 Codec dimensions
• Width: 300 mm / 11.8 in.
• Height: 34 mm / 1.4 in.
• Depth: 180 mm / 7.1 in.
• Weight: 1.4 kg / 3.1 lb
