Basic Operation
Viewing Live Images via
Mouse Control (continued)
Viewing Images Using the PTZ Features
(continued)
Digital Zoom
By selecting the [Digital Zoom] check box in the [PTZ
Control] section, you are able to use digital zoom on images
from any camera displayed in the view. When digital zoom is
enabled, you will see a small overview frame at the bottom
right corner.
PTZ Navigation Button
[Digital Zoom]
[Live] Screen
Memo :
● The recorded images will not be recorded in zoom even
when digital zoom is used.
● When digital zoom is used, the recording frame rate may
decrease due to an increase in the load factor of VR-
N1600U/E.
● To exit the digital zoom function, deselect the [Digital
Zoom] check box.
Note :
● When the [Digital Zoom] check box is selected, the actual
PTZ operation will not be performed.

Using Preset Positions

Making a selection from the preset list enables you to move
the orientation of the camera to a preset position. (APage
80 [Defining a Preset Position])
Memo :
● The buttons are only available if the camera is a PTZ
camera.
[Presets] List
1
Click the [K] button on the [Presets] list in the
[PTZ Control] section
● The preset list appears on the screen.
2
Select a preset position from the preset list
● The camera moves to the preset position.

Other Useful Functions

Listening to Audio Sound
To listen to live audio sound, select the required audio source
from the [Audio Source] list of the [Audio] section.
To temporarily mute the live audio sound, select the [Mute]
check box.
Select check
Note :
● When the audio source is selected by multiple
surveillance computers, the sound quality may
deteriorate.
● The audio setting is set to No Audio Sources when you
return from the setting screen to [Live]. Select the audio
parameters again.
[Live] Screen
