Toshiba GR200 Series Instruction Manual page 1370

Appendix 3 Typical external connection
Case and terminal
types
Type using
compression terminals
Type using ring
terminals
Typical external
connection diagram
Size case Examples of hardware codes
1 / 1 size case GRZ200-11-434-00-66-30-110
1 / 2 size case GRZ200-11-434-00-66-31-110
1 / 1 size case GRZ200-11-234-00-66-30-110
1 / 2 size case GRZ200-11-227-00-66-31-110
1 / 1 size case GRZ200-11-434-00-66-30-110
- 1349 -
6F2S1915 (0.46)
Figures (pages)
Figure 3-1 (1350)
Figure 3-2 (1352)
Figure 3-3 (1351)
Figure 3-4 (1353)
Figure 3-5 (1354)
GRZ200 (Soft 031 & 032)
