USB communication
The IED front panel has an USB receptacle in a B-type to connect with a local PC for
engineering. The user can select a transmission speed, which is shown below, by the operation
of the setting menu, as shown in Figure 11.5-1.
Setting of USB (Function ID: 231701)
Setting item
USBCOM_BRATE_SW
USBCOM
10:48
USBCOM_BRATE_SW +
921.6kbps
Figure 11.5-1 USB setting menu (on IED screen)
Unit
Range
s
115.2 / 921.6 kbps
- 1247 -
1/1
Contents
Baud rate Switch for USB Com port
6F2S1915 (0.46)
Default setting
Notes
value
921.6
GRZ200 (Soft 031 & 032)
