Binary Input
10:48
Slot#1
_Slot#3
Slot#4
Figure 12.6-5 Selection of slot and binary input circuit
Note: This screen is a sample. The slot numbers displayed depend upon the
configuration of the binary IO module in each IED.
CPL setting: Figure 12.6-6 is an example of a "Common" setting. From this
screen, the user can set a threshold level and the number of comparisons
feature for contact chatter for all binary input circuits.
Figure 12.6-6 Common screen
For example, Figure 12.6-7 shows the CPL setting for binary input circuit (BI1).
The timer and the inverse switch can be activated when On is set for setting
[BI1_CPL]. Press key ENTER to commence the setting of a switch or parameter.
Note: Setting items "On Delay timer and others" are displayed when the user sets
[BI*_CPL] On.
2/3
>
[►]
>
>
Common
10:48
Thres_Level
Low
Cmp_Num
BI1
10:48
BI1_CPL
Off
On Delay Timer
0.000
Off Delay Timer
0.000
SW
Inverse-SW
Normal
Figure 12.6-7 CPL setting
- 1287 -
Slot#3
10:48
_Common
BI1
BI2
BI3
BI4
BI5
1/2
+
+
4
1/2
+
+
s
+
s
+
