4 . 1 . 3 L o a d B a l
4 . 1 . 3 L o a d B a l
Vigor3900 supports a load balancing function. It can assign traffic with protocol type, IP
address for specific host, a subnet of hosts, and port range to be allocated in WAN interface.
User can assign traffic category and force it to go to dedicate network interface based on the
following web page setup.
In the WAN group, click the Load Balance Policy option.
R R u u l l e e
This page will make the packets be transmitted with user defined profiles with IP address,
protocol and WAN profile that is different with default route.
Each item will be explained as follows:
Item
Add
Edit
Delete
Refresh
Move Up
Move Down
Profile
Enable This Profile
Vigor3900 Series User's Guide
a n c e P o l i c y
a n c e P o l i c y
Description
Add a new rule profile.
Modify the selected rule profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Remove the selected rule profile.
To delete a rule, simply select the one you want to delete and
click the Delete button.
Renew current web page.
Change the order of selected profile by moving it up.
Change the order of selected profile by moving it down.
Display the name of the rule.
Display the status of the profile. False means disabled; True
means enabled.
71
