Preshared Key
WAN Profile
DHCP LAN Profile
IKE Port
NAT-Port
IPSec MSS
GRE over IPSec MSS
Apply
Cancel
4 . 8 . 6 V P N P r o f
4 . 8 . 6 V P N P r o f
The router allows you to create VPN profiles via the protocol of IPSec or PPTP (dial-in or
dial-out).
The router supports up to 500 VPN tunnels simultaneously. The following figure shows the
summary table.
Each item will be explained as follows:
Item
Add
Edit
Vigor3900 Series User's Guide
Specify a key for IKE authentication
Confirm Pre-Shared Key- Retype the characters to confirm
the pre-shared key.
Choose a WAN interface profile to be used.
Choose one of the LAN profiles for VPN.
Type the UDP port number for Internet Key Exchange (IKE)
traffic to the VPN server.
Type the UDP port number for IPSec network address
translator traversal (NAT-T) traffic.
Type the port number for IPSec MSS.
Type the port number for GRE over IPSec MSS.
Click it to save the configuration.
Click it to discard the settings configured in this page.
i l e s
i l e s
Description
Add a new profile.
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
219
