Enable This Profile
Always On
Server IP Address
PPTP User Name
PPTP Password
Local IP/Subnet
Mask
Remote IP/Subnet
Mask
Route/NAT Mode
If you choose IPSec as the Type, you will get the following screen:
Available parameters are listed as follows:
Item
Profile
Enable This Profile
Auth Type
Certificate
Preshared Key
Check this box to enable such profile.
Click Enable to make router always keeping connection.
Type the IP address of PPTP server.
Type a user name for authentication in PPTP connection.
Type a password for authentication in PPTP connection.
Type the IP address and subnet mask of local host.
Type the LAN IP address and LAN subnet mask for the
remote host.
Specify the purpose for such profile.
Description
Display the name of the VPN profile.
Check this box to enable such profile.
The authentication to be used by Pre-Shared Key or RSA
Signature. Choose PSK or RSA for such profile.
Choose a local certificate from the drop down list.
Type a pre-shared key for authentication if PSK is selected
