VigorAccess IP DSLAM
Quick Start Guide
Version: 1.0
Date: 2006/05/22

Advertisement

Table of Contents
loading

Related Manuals for Draytek Vigor VigorAccess

Summary of Contents for Draytek Vigor VigorAccess

  • Page 1 VigorAccess IP DSLAM Quick Start Guide Version: 1.0 Date: 2006/05/22...
  • Page 3 This quick start guide will guide you to finish the basic configuration for accessing Internet with VigorAccess IP Above diagram shows the basic network topology (example) among master device, slave device, MDF, CPE (ATU-R) router and user’s computer. One thing is important – always set the VPI/VCI value for the CPE the same as the ones configured in master and slave IP DSLAM.

  • Page 4: How To Login With A Terminal Emulator Software

    For Master Device Connect to a PC through CONSOLE port. It is useful for controlling the device locally. How to Login with a Terminal Emulator Software For Master Device 1. The default setting is “baud rate 9600, no parity, and 8 bit with 1 stop bit (N,8,1)”. 2.

  • Page 5: How To Check The Connectivity

    Please turn on the interface that connected to a slave device. In the above picture, you have to turn ON the interface G1, G4 and G6 for they connect to different slave devices. Use the command on Master below to turn on the interface.

  • Page 6: How To Save The Configuration

    To display the DSL module information inside the master/slave device Login the specified DSL module. Type the following command to get the DSL module information $get system info How to Save the Configuration To save the configuration for the controller Type the following command to save the configuration.

  • Page 7: How To Login With Telnet

    How to Configure IP Address for Slave-Standalone Device A slave device can work alone without connecting the master device. There are two types of slave device that user might have. One is the device with two fast-ethernet interface version; the other is the device with one gigabit-ethernet interface version.

  • Page 8: How To Configure Inband Ip Address

    – – Here provides some general and common commands used in IP DSLAM for users to configure the IP DSLAM Controller. How to configure Inband IP Address Users can use the following commands to configure the inband IP address for the UP-LINK interface or inband management.

  • Page 9: How To Configure Ntp And Time

    Admin/network> route default 0.0.0.0 Admin/network> route -a <TargetIP> <NetMask> <GatewayIP> Admin/network> route -e <RtIdx> <TargetIP> <NetMask> <GatewayIP> Admin/network> route -d <RtIdx> Admin/network> route -D How to configure NTP and Time Users can use the following commands to configure the NTP server IP and the polling interval or not to use the NTP by configuring the current time settings manually, including the time zone and the daylight saves time.

  • Page 10: How To Upgrade Firmware

    How to Upgrade Firmware Users can use the following commands to upgrade new firmware. Make sure you have prepared a TFTP server on a host and put the firmware (ipdslam.all for example) in the right directory of the TFTP server Command Admin>...

  • Page 11: How To Monitor Dsl Status

    Here provides some general and common commands used in IP DSLAM for users to configure the IP DSLAM DSL Module. Note: Please refer to the Command Line Interface manual for getting more commands that IP DSLAM supports. Contact your dealer for advanced information. How to Monitor DSL Status Users can use the following command to check the status for specified DSL port.

  • Page 12: How To Change Adsl Line Rate

    How to Change ADSL Line Rate Users can use the following command to change the ADSL Line Rate for specified DSL port. The commands are listed as below. Command $modify adsl line intf ifname dsl-* disable $modify adsl line profile ifname dsl-* atucintlmaxtxrate 0x7e0000 $modify adsl line intf ifname dsl-* enable...

  • Page 13: How To Change Management Ip Address For Existing Ethernet Port

    How to Change Management IP Address for Existing Ethernet Port Users can use the following command to change management IP address for existing Ethernet port. The commands are listed as below. Command $modify aggr intf ifname aggr-0 ip <new-ip> mask <new-mask> $modify ethernet intf ifname eth-* ip <new-ip>...

  • Page 14: How To Setup Port Vlan Id (Pvid)

    How to Setup Port VLAN ID (PVID) Users can use the following command to setup port VLAN ID. The commands are listed as below. Command $modify gvrp port info portid <bridge-port-id> portvalnid <default-pvid> How to Filter MAC Address by Port Users can use the following command to filter MAC address by port.

  • Page 15: How To Enable Spanning Tree Protocol

    $modify filter rule entry ruleid <id2> status enable $create filter rule map ifname all ruleid <id2> stageid 1 How to Enable Spanning Tree Protocol Users can use the following command to enable spanning tree protocol. The commands are listed as below.

  • Page 16: How To Upgrade Full Image Remotely

    How to Upgrade Full Image Remotely Users can use the following command to remotely upgrade full image. Make sure you have prepared TFTP server, vendor supplied TEImage.bin.gz, and put TEImage.bin.gz into root directory of TFTP server. The commands are listed as below. Command $reboot config safe $create ethernet intf ifname eth-0 ip <ip_address>...
