Draytek Vigor2830 Series User Manual page 242

Available settings are explained as follows:
Item
Backup Profile List
Vigor2830 Series User's Guide
Description
Set to Factory Default - Click to clear all VPN
TRUNK-VPN Backup mechanism profile.
No – The order of VPN TRUNK-VPN Backup mechanism
profile.
Status - "v" means such profile is enabled; "x" means such
profile is disabled.
Name - Display the name of VPN TRUNK-VPN Backup
mechanism profile.
Member1 - Display the dial-out profile selected from the
Member1 drop down list below.
Active - "Yes" means normal condition. "No" means the
state might be disabled or that profile currently is set with
Dial-in mode (for call direction) in LAN-to-LAN.
Type - Display the connection type for that profile, such as
IPSec, PPTP, L2TP, L2TP over IPSec (NICE), L2TP over
IPSec(MUST) and so on.
Member2 - Display the dial-out profile selected from the
Member2 drop down list below.
Advanced – This button is available only when LAN to
LAN profile (or more) is created.
232
