For Vigor2830N/ Vigor2830N-Plus - Draytek Vigor2830 Series User Manual

1 . 2 . 2 F o r V i g o
1 . 2 . 2 F o r V i g o
LED
ACT (Activity)
USB
CSM
WLAN
DSL
WAN2
DoS
VPN
QoS
LED on Connector
GigaLAN 1/2/3/4
WAN 2 (Giga)
Vigor2830 Series User's Guide
r 2 8 3 0 n / V i g o r 2 8 3
r 2 8 3 0 n / V i g o r 2 8 3
Status
Blinking
Off
On
Blinking
On
On
Blinking
On
Blinking
On
Blinking
On
Blinking
On
On
Left LED On
(Green)
Off
Blinking
Right LED On
(Green)
Off
Left LED On
(Green)
Off
Blinking
Right LED On
(Green)
Off
0 n - p l u s
0 n - p l u s
Explanation
The router is powered on and running normally.
The router is powered off.
USB device is connected and ready for use.
The data is transmitting.
The profile(s) of CSM (Content Security
Management) for IM/P2P, URL/Web Content Filter
application is enabled from Firewall >>General
Setup. (Such profile must be established under
CSM menu).
Wireless access point is ready.
It will blink slowly while wireless traffic goes
through.
If ACT and WLAN LEDs blink quickly and
simultaneously when WPS is working, and it will
return to normal condition after two minutes. (You
need to setup WPS within 2 minutes.)
The router is ready to access Internet through DSL
link.
Slowly: The DSL connection is ready.
Quickly: The connection is tranning.
The WAN2 connection is ready.
It will blink while transmitting data.
The DoS/DDoS function is active.
It will blink while an attack is detected.
The VPN tunnel is active.
The QoS function is active.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps when left
LED is on.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps when left
LED is on.
4
