NOTE
DMA/33 device on each IDE channel. This is due to
the fact that the length of the three-connector cable
required for the configuration might cause signal
degradation.
Two Ultra DMA/33 IDE devices can be used on the
same PCI/IDE channel in a desktop system if
neither device is run in Ultra DMA/33 mode.
You can run two Ultra DMA/33 devices in Ultra
DMA/33 mode in a desktop system if one device is
connected to the primary PCI/IDE channel, and the
other is connected to the secondary IDE channel.

Connecting Device Cables

The cables used for installing optional storage devices
include the following:
T
diskette drive signal cable
T
IDE signal cables
T
internal SCSI cables
T
system power cables.
5-44 Installing Options
Desktop systems support only one Ultra
