Replacing the Minitower Chassis Floor
Replace the chassis floor as follows.
Place the system unit on its right side.
1.
Line up the chassis floor with the chassis so its untabbed
2.
edge is along the lower (right) edge of the chassis.
The tabs along the upper edge of the floor must line up
with the slots in the upper edge of the chassis.
Angle the upper edge of the floor away from the chassis
3.
and position the lower edge in the groove along the
chassis edge.
Press the floor up against the bottom of the chassis.
4.
Slide the floor toward the front of the chassis to lock the
5.
tabs in the slots.
Secure the floor to the chassis with the thumbscrew.
6.
EXPANSION BOARDS
Your system supports industry standard architecture
(ISA) 8- and 16-bit expansion boards (Plug and Play and
non-Plug and Play). It also supports 32-bit Peripheral
Component Interconnect (PCI) expansion boards, which are
Plug and Play.
With Plug and Play expansion boards, you can install a
board in an expansion slot without changing the hardware
settings. There are no system resource conflicts to resolve.
Plug and Play automatically configures the board for the
system.
Installing Options 5-17
