4.1.2 CTC Software Installed on the PC or UNIX Workstation

You can view the software versions that are installed on one ONS 15600 by clicking the Maintenance >
Software tabs in node view. Click the tabs in network view to display the software versions installed on
all the network nodes.
4.1.2 CTC Software Installed on the PC or UNIX Workstation
When you connect to the ONS 15600, the TSC card automatically downloads the CTC software to your
computer, where it is automatically installed if you have the correct Java Runtime Environment (JRE).
The automatic download/installation process ensures that your computer is running the same CTC
software version as the TSC you are accessing. The CTC software files are stored in the temporary
directory designated by your computer's operating system. You can use the Delete CTC Cache button to
remove files stored in the temporary directory. If the files are deleted, they are downloaded the next time
you connect to an ONS 15600. Downloading the Java archive (JAR) files for CTC takes several minutes
depending on the bandwidth of the connection between your workstation and the ONS 15600. For
example, JAR files downloaded from a modem or a SONET data communications channel (SDCC)
network link requires more time than JAR files downloaded over a LAN connection.
During network topology discovery, CTC polls each node in the network to determine which one
contains the most recent version of the CTC software. If CTC discovers a node in the network that has
a more recent version of the CTC software than the version you are currently running, CTC generates a
message stating that a later version of the CTC has been found in the network, and offers to install the
CTC software upgrade. If you have network discovery disabled, CTC will not seek more recent versions
of the software. Unreachable nodes are not included in the upgrade discovery.
Upgrading the CTC software will overwrite your existing software. You must restart CTC after the
Note
upgrade is complete.

4.2 CTC Installation Overview

To connect to an ONS 15600 using CTC, enter the ONS 15600 IP address in the URL field of a web
browser, such as Netscape Navigator or Microsoft Internet Explorer. After connecting to an ONS 15600,
the following events occur automatically:
Each ONS 15600 has a unique IP address that you use to access the ONS 15600. The initial IP address,
Note
192.168.1.2, is the default address for ONS 15600 access and configuration.
1.
2.
3.
4.
Cisco ONS 15600 Reference Manual, R8.0
4-2
A CTC launcher applet is downloaded from the TSC to your computer's temporary directory. (If
these files are deleted, they are automatically reinstalled the next time you connect to the
ONS 15600.)
The launcher determines whether your computer has a CTC release matching the release on the
ONS 15600 TSC.
If the computer does not have CTC installed, or if the installed release is older than the TSC version,
the launcher downloads the CTC program files from the TSC.
The launcher starts CTC. The CTC session is separate from the web browser session, so the web
browser is no longer needed. If you log into an ONS 15600 that is connected to ONS 15600s with
older versions of CTC, or to Cisco ONS 15454s or ONS 15327s, CTC element files are downloaded
