EPSON AcuLaser C1900/AcuLaser C900

1.4.5 Printer Setting Items (Only with AcuLaser C900)

This section describes setting items for AcuLaser C900.
For setting of the items described below, use the "Printer Setting" dialog box on the
"Optional Settings" of the printer driver.
Since there are no character strings administrated by the printer, the names of setting
items and setting values referred to below are only for explanation. Therefore, these
names may not match the character strings displayed in driver's user interfaces or the
status sheet.

1.4.5.1 Setting Items stored on the Printer Side

Values shown in bold and underlined characters are the factory default setting values.
Table 1-43. Setting Items stored on the Printer Side
Setting
Sleep 30, 60, 120, 180 minutes, OFF
*1
Paper Source Priority MP Tray , LC
MP Tray Size A4 *1 , A5, B5, LT
C10, DL, C5, C6, IB5, Yokei#0, Yokei#4, Yokei#6
LC Size A4, LT
Toner Out Error Stop, Continue
Fuser Temp. -20 ~ 0 ~ 20
Note *1: The default setting is determined depending on the destination.
Standby
Set the power saving function to reduce the power consumption when the printer is
in the standby mode.
The printer can use five setting values, while the driver is limited to:
ON (30 minutes), OFF
Product Description
Value
*1
, LC Only
*1 , HLT, GLT, EXE, Postcard, W Postcard, MON,
Paper Source Priority
Set a priority order when Auto Selection is selected by the paper source setting and
the paper sources matches the designated paper size.
This is the same function as the "MP Mode" function of ESC/Page models.
MP Tray : MP tray > Cassette
LC : Cassette > MP tray
LC only : Cassette
However, to continue printing when the paper sources has no paper which matches the
target paper size, papers are fed from the paper sources in the order of MP tray >
cassette.
The default setting differs depending on the destinations: "MP tray" for worldwide
models.
NOTE: The printer can set "LC only", but the driver cannot select it since the
same function is can be achieved by selecting a cassette from the paper
source.
MP Tray Size
Assign a paper size for the MP tray. If the printing is continued after the "Paper
Set" error occurrence and the paper size designated by the printing data matches
the paper size which is actually fed, the paper size will be stored in memory. The
default value is either "A4" or "LT" depending on the jumper setting (R190/
INPT0) on the controller board.
NOTE: The paper sizes which can be handled by the MP Tray Size function of
AcuLaser C900 driver is limited to:
A4, A5, B5, LT, HLT, GLT, EXE, MON, C10, DL, C5, C6, IB5
LC Size
Specify a paper size for the optional cassette size. The default value is not affected
by the controller configurations and is always set to "A4".
Toner Out Error
Select whether "uuuu Toner Out" is to be indicated and the printing is to be
stopped or "uuuu Toner Low" is to be kept indicated when the amount of
remaining toner indicated by the toner counter reaches 0%.
Control Panel
Revision B
59
