OCR Type A230
10.3 Set the Judgment Conditions
You can set judgment conditions for the number of leads, lead width, and lead pitch.
3. Detect Judgment
4. Width Judgment
5. Pitch Judgment
Detect Judgment
Produces an OK result if the number of leads detected matches the setting.
Width Judgment
Set maximum and minimum limits for the width of the leads. An OK result is produced
if the width is between these limits. Perform an inspection on a good article to obtain
the width value (use the Result item to verify the value) and use this value as an aid in
setting the limits (refer to the following page).
Pitch Judgment
Set maximum and minimum limits for the lead pitch. An OK result is produced if the pitch
is between these limits. Perform an inspection on a good article to obtain the pitch value
(use the Result item to verify the value) and use this value as an aid in setting the limits
(refer to the following page).
128
<510.9, 0.0>
<510.9, 0.0>
Lead Inspection Checker
10.3 Set the Judgment Conditions
10 − 9
