Board Component Descriptions

Overview

This chapter provides a description of the board's components and features.
the components and references the respective schematic page numbers. Component locations
are shown in Figure

Component Descriptions

Zynq UltraScale+ RFSoC XCZU49DR

[Figure 2, callout 1]
The ZCU216 board is populated with the Zynq
which combines a powerful processing system (PS) and user-programmable logic (PL) in the same
device. The processing system in a Zynq UltraScale+ RFSoC features the Arm
A53 64-bit quad-core processor and Cortex™-R5F dual-core real-time processor.
The V supplies are user adjustable through PMBUS with the voltage ranges to support
CCINT
whichever Zynq UltraScale+ RFSoC speed grade is on the evaluation board. See the Zynq
UltraScale+ RFSoC Data Sheet: DC and AC Switching Characteristics (DS926) for more information.
