User PMOD GPIO Headers

[Figure 2, callout 22]
The ZCU216 evaluation board supports two right-angle PMOD GPIO receptacles J46 and J47.
The 3.3V PMOD nets are level-shifted and are wired to the ZU49DR device U1 bank 88.
For more information on the pmod interface, visit the
The detailed RFSoC connections for the feature described in this section are documented in the
ZCU216 board XDC file, referenced in

User I/O

[Figure 2, callout 23, 24, and 25]
The ZCU216 board provides these user and general purpose I/O capabilities:
• Eight sets of 3 RGB LEDs (24 LEDs total) (callout 23)
RGB_[R,G,B]_LED_0: DS46
○
RGB_[R,G,B]_LED_1: DS47
○
RGB_[R,G,B]_LED_2: DS48
○
RGB_[R,G,B]_LED_3: DS49
○
RGB_[R,G,B]_LED_4: DS50
○
RGB_[R,G,B]_LED_5: DS51
○
RGB_[R,G,B]_LED_6: DS52
○
RGB_[R,G,B]_LED_7: DS53
○
• 8-position user DIP switch (callout 23)
GPIO_DIP_SW[7:0]: SW14
○
• Five user pushbuttons and a CPU reset PB switch (callouts 24 and 25)
GPIO_SW_[NWCES]: SW8, SW9, SW10, SW11, SW12
○
CPU_RESET: SW13
○
The detailed RFSoC connections for the feature described in this section are documented in the
ZCU216 board XDC file, referenced in
UG1390 (v1.1) July 10, 2020
ZCU216 Board User Guide
Chapter 3: Board Component Descriptions
Digilent
Appendix B: Xilinx Design
Appendix B: Xilinx Design
website.
Constraints.
Constraints.
