Chapter 5 - Servicing
CAUTION
The DIMMs are hot to the touch for some time after the system is powered down. Allow time for
the DIMMs to cool before handling them. Handle the DIMMs by the edges and avoid touching
DIMM components.
To add additional memory
1. Perform the steps in section
2. Remove the access panel. Refer to section
3. Swing the access panel up to expose the DIMM memory slots.
4. While wearing a grounded ESD wrist strap, press the socket ejectors on the memory module
socket down to allow the memory module to be inserted into the socket.
5. Insert the memory module as described in section
6. Align the memory module's edge connector with the alignment key on the memory module socket,
and insert the memory module into the socket.
ATTENTION
The memory module socket has an alignment key that allows you to install the memory
module in the socket only in one way.
7. Press down the memory module with your thumbs while pulling up on the socket ejectors with your
index fingers to lock the memory module into the socket.
When the memory module is properly seated in the socket, the socket ejectors on the memory
module socket align with the socket ejectors on the other sockets that have memory modules
installed.
Remove the server from the
Removing the access
Memory
- 49 -
rack.
panel.
configuration.
