2. Specifications
2.1. Performance specifications
Item
2MLF-AV8A (Voltage Input Type)
Signed value
Precise value
Percentile value
•
•
Analog input range
1 ~ 5V
Maximum
resolution
0 ~ 5V
0 ~ 10V
-10 ~ 10V
±0.2% or less (when ambient temperature is 25 ±5
Accuracy
±0.3% or less (when ambient temperature is 0 ~ 55
Maximum
250μs/channel
conversion speed
Absolute maximum
±15V
input
Analog input
8 channels/ module
channels
Photo-coupler isolation between input terminal and PLC power (no isolation between
Isolation method
channels)
Terminal
18-point terminal
connected
I/O addresses
Fixed type: 64 points, Variable type: 16 points
assigned
22
-8000 ~ 8000
4000 ~ 20000
0 ~ 10000
16-bit binary value (data: 14 bits)
You can individually set the format of digital output data for each channel either from
user program or through user-friendly GUI I/O parameter function in SoftMaster.
Resolution
(1/16000)
0.250mV
0.3125mV
0.625mV
1.250mV
Analog Input Module 2MLF-AV8A, AC8A User's Guide
Specifications
2MLF-AC8A (Current Input Type)
Analog input
range
4 ~ 20mA
0 ~ 20mA
o
C)
o
C)
±30mA
