CHAPTER 12 16-BIT INPUT/OUTPUT TIMER

12.3.1 Free-running timer

This section shows the configuration and explains the functions of free-running timer
registers.
■
List of free-running timer registers
Figure 12.3-4 shows a list of the free-running timer registers.
000067
H
000066
H
000063
H
000062
H
000065
H
000064
H
R/W : Readable/Writable
■
Compare clear register (CPCLR)
Figure 12.3-5 shows the bit configuration of the compare clear register (CPCLR).
Figure 12.3-5 Bit configuration of the compare clear register (CPCLR)
000067 CL15 CL14 CL13 CL12 CL11 CL10 CL09 CL08
H
(R/W) (R/W) (R/W) (R/W) (R/W) (R/W) (R/W) (R/W) Initial value XXXXXXXX
000066 CL07 CL06 CL05 CL04 CL03 CL02 CL01 CL00
H
(R/W) (R/W) (R/W) (R/W) (R/W) (R/W) (R/W) (R/W) Initial value XXXXXXXX
R/W : Readable/Writable
The compare clear register (CPCLR) is a 16-bit length compare register used to make a
comparison with the free-running timer. An initial value of a register is undefined. Therefore, set
the initial value, then allow the interrupt operation. This register requires word access.
When the MODE bit of the timer counter control status register (TCCS) is set to "1", the free-
running timer value is initialized to "0000
free-running timer. When this register value matches the value of the free-running timer, a
compare clear interrupt flag is set. When the compare interrupt flag is set to "1", an interrupt
request issues to the CPU at allowing the interrupt operation.
