Washing Machine WNF 9448 AE20 User‘s Manual Document Number 2820524006/ 05-05-14.(13:29) - Page 2 Please read this user manual first! Dear Customer, Thank you for prefering an Blomberg product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Important instructions for safety and 5 Operating the product environment 5.1 Control panel ..... . .22 1.1 General safety . -
Page 4: Important Instructions For Safety And Environment
Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 General safety • This product can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack experience and knowledge provided that they are supervised or trained on the safe usage of the product and the risks it brings out. -
Page 5: Intended Use
Important instructions for safety and environment • Use detergents, softeners and supplements suitable for automatic washing machines only. • Follow the instructions on the textile tags and on the detergent package. • The product must be unplugged during installation, maintenance, cleaning and repairing procedures. -
Page 6: Children's Safety
Important instructions for safety and environment 1.3 Children's safety • Packaging materials are dangerous to children. Keep packaging materials in a safe place away from reach of the children. • Electrical products are dangerous for the children. Keep children away from the product when it is in use. -
Page 7: Package Information
Important instructions for safety and environment 1.4 Package information • Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. -
Page 8: Your Washing Machine
Your washing machine 2.1 Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark Blomberg Model name WNF9448AE20 Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) -
Page 9: Overview
Your washing machine 2.2 Overview 1- Power cable 2- Top panel 3- Control panel 4- Filter cap 5- Adjustable feet 6- Loading door 7- Detergent drawer 8- Drain hose 9 / EN Washing Machine /User’s Manual... -
Page 10: Package Contents
Your washing machine 2.3 Package Contents 1- Power cable 2- Drain hose 3- Transportation safety bolts * 4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.) a- Electronical water shut-off b- Mechanical water shut-off c- Standard 5- Liquid detergent container** 6- User Manual... -
Page 11: Installation
Installation 3.2 Removing packaging Refer to the nearest Authorised Service Agent for installation of the product. To make the product reinforcement ready for use, review the information in the user Tilt the machine backwards to remove the manual and make sure that the electricity, tap packaging reinforcement. -
Page 12: Connecting Water Supply
Installation 3. Attach the plastic covers supplied in the User blue hose (right) (max. 25 ºC) is for cold water Manual bag into the holes on the rear panel. (P) inlet. Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the future. -
Page 13: Connecting To The Drain
Installation 3.5 Connecting to the drain water leak failures, the connection between the extension hose and the drain hose of the • The end of the drain hose must be directly product must be fitted well with an appropriate connected to the wastewater drain or to the clamp as not to come off and leak. - Page 14 Installation • Connection must comply with national The moulded plug on this appliance incorporates a regulations. 13A fuse. Should the fuse need to be replaced an • Power cable plug must be within easy reach ASTA approved BS1362 fuse of the same rating after installation.
- Page 15 Installation important Transportation of the product 1. Unplug the product before transporting it. Fitting a different plug 2. Remove water drain and water supply As the colours of the wires in the mains lead connections. of this appliance may not correspond with the 3.
-
Page 16: Preparation
Preparation 4.1 Sorting the laundry • Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature. • Always obey the instructions given on the garment tags. LAUNDRY WASH SYMBOLS Machine Wash Symbols wASH Maximum Water Temperatures ... -
Page 17: Preparing Laundry For Washing
Preparation 4.2 Preparing laundry for washing 4.3 Things to be done for energy saving • Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons Following information will help you use the will damage the machine. Remove the metal product in an ecological and energy-efficient pieces or wash the clothes by putting them in a manner. -
Page 18: Initial Use
Preparation 4.4 Initial use 4.6 Loading the laundry Before starting to use the product, make sure 1. Open the loading door. that all preparations are made in accordance 2. Place laundry items loosely into the machine. with the instructions in sections “Important safety 3. - Page 19 Preparation Using liquid detergents • Do not select a programme with prewash if you are using a detergent bag or dispensing ball. if the product contains a liquid detergent cup: Place the detergent bag or the dispensing ball • Make sure that you have placed the liquid directly among the laundry in the machine.
- Page 20 Preparation Using starch • Add liquid starch, powder starch or the fabric dye into the softener compartment. • Do not use softener and starch together in a washing cycle. • Wipe the inside of the machine with a damp and clean cloth after using starch. Using bleaches •...
-
Page 21: Tips For Efficient Washing
Preparation 4.8 Tips for efficient washing Clothes Light colours and Delicates/woolens/ Colours Dark colours whites Silks (Recommended (Recommended (Recommended (Recommended temperature range temperature range temperature range temperature range based on soiling level: based on soiling level: based on soiling based on soiling 40-90ºC) cold-40ºC) level: cold-40ºC) -
Page 22: Operating The Product
Operating the product 5.1 Control panel Spin Speed Adjustment button On / Off button Display Delayed Start buttons (+ / -) Temperature Adjustment button Auxiliary Function buttons Programme Selection knob Start / Pause / Cancel button 5.2 Display symbols - Spin Speed indicator - Temperature indicator - Spin symbol - Temperature symbol... -
Page 23: Preparing The Machine
Operating the product 5.3 Preparing the machine For curtains and tulle, use the Synthetic 40˚C programme with prewash and anti-creasing 1. Make sure that the hoses are connected tightly. functions selected. As their meshed texture 2. Plug in your machine. causes excessive foaming, wash the veils/tulle by 3. -
Page 24: Special Programmes
Operating the product washes laundry with a very gentle washing action Do not load more than 1 double fibre duvet (200 to not to damage clothes. x 200 cm). Do not wash your duvets, pillows and etc. that • Fast Full Load contain cotton in the machine. -
Page 25: Spin Speed Selection
Operating the product 5.9 Spin speed selection If you scroll to cold wash option and press Temperature Adjustment button again, the Whenever a new programme is selected, the recommended temperature for the selected recommended spin speed of the selected programme appears on the display. Press the Temperature Adjustment button again to programme is displayed on the spin speed decrease the temperature. -
Page 26: Programme And Consumption Table
Operating the product 5.10 Programme and consumption table Auxiliary functions Selectable temperature Programme range °C 2.49 1600 • • • • • 90-Cold Cottons 1.78 1600 • • • • • 90-Cold 0.97 1600 • • • • • 90-Cold Bedding 0.67 1200... -
Page 27: Auxiliary Function Selection
Operating the product 5.11 Auxiliary function selection F2 appears on the display when you select this function (b). Select the desired auxiliary functions before starting the programme. Furthermore, you may When you select this function, load your also select or cancel auxiliary functions that are machine with half of the maximum laundry specified in the programme table. -
Page 28: Time Display
Operating the product • Pet hair removal Delayed start With the Delayed Start function the startup This function helps to remove pet hair that remain of the programme may be delayed up to 24 on your garments more effectively. hours. Delayed start time can be increased by When you select this function, Prewash and Extra increments of 30 minutes. -
Page 29: Starting The Programme
Operating the product Cancelling the Delayed Start function Softener Softener symbol indicating that the softener step If you want to cancel the delayed start countdown has started appears on the display. and start the programme immediately: 1. Press Start / Pause / Cancel button. “:” sign Spin in the middle of the delayed start time on the Appears at the beginning of the final spin step... -
Page 30: Child Lock
Operating the product 5.17 Child Lock Changing the speed and temperature settings for auxiliary functions Use Child Lock function to prevent children from Depending on the step the programme has tampering with the machine. Thus you can avoid reached, you may cancel or activate the auxiliary any changes in a running programme. -
Page 31: Cancelling The Programme
Operating the product 5.18 Cancelling the programme 5.21 Your machine is equipped with a “Standby Mode” Press and hold Start / Pause / Cancel button for 3 seconds. Start symbol flashes. Symbol of In case of not starting any programme or waiting the step at which the programme was cancelled without making any other operation when the remains lit. -
Page 32: Maintenance And Cleaning
Maintenance and cleaning Service life of the product extends and frequently If your detergent drawer is the one indicated in the faced problems decrease if cleaned at regular following figure: intervals. 6.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time. -
Page 33: Cleaning The Body And Control Panel
Maintenance and cleaning After every washing make sure that no foreign 2. Remove the nuts of the water intake hoses to substance is left in the drum. access the filters on the water intake valves. Clean them with an appropriate brush. If the filters are too dirty, take them out by means of pliers and clean them. - Page 34 Maintenance and cleaning place. d. Turn the pump filter to take it out. Discharging the water when the product does not have an emergency draining hose: If the filter cap is one piece, pull the cap from both sides at the top to open. a.
-
Page 35: Troubleshooting
Troubleshooting Problem Reason Solution Programme cannot be Washing machine has switched to self Š Press and hold Start / Pause / Cancel protection mode due to a supply problem (line button for 3 seconds to reset the machine started or selected. voltage, water pressure, etc.). - Page 36 Troubleshooting Problem Reason Solution washing takes longer Water pressure is low. Š Machine waits until taking in adequate amount of water to prevent poor washing time than specified in the quality due to the decreased amount of manual.(*) water. Therefore, the washing time extends. Voltage might be low.
- Page 37 Troubleshooting Problem Reason Solution washing performance is Insufficient amount of detergent has been used Š Use the recommended amount of detergent over a long period of time. appropriate for water hardness and the poor: Laundry turns gray. laundry. (**) Washing was made at low temperatures for a Š...
- Page 38 Troubleshooting Problem Reason Solution Laundry became stiff after Insufficient amount of detergent is used. Š Using insufficient amount of detergent for the water hardness can cause the laundry washing. (**) to become stiff in time. Use appropriate amount of detergent according to the water hardness.
- Page 39 Troubleshooting Problem Reason Solution Foam is overflowing from Too much detergent is used. Š Mix 1 tablespoonful softener and ½ l water and pour into the main wash compartment the detergent drawer. of the detergent drawer. Š Put detergent into the machine suitable for the programmes and maximum loads indicated in the “Programme and consumption table”.
- Page 40 Blomberg, 36-38 Caxton Way, Watford, Hertfordshire, WD18 8UF Tel: 0800 597 8560 Fax: 0845 6004922 email: service@blomberguk.com www.blomberguk.com...
