4.11 Carriage Section
The carriage section comprises the following five mechanisms:
• BJ cartridge loading mechanism
• Carriage drive mechanism
• Print deviation compensation mechanism
• Paper feed motor drive switching mechanism
• Pumping operation state detection mechanism
loading mechanism
Pumping operation state
detection mechanism
Paper feed motor drive switching mechanism
Fig. 4-59 Carriage Section
BJ cartridge
Print deviation
compensation mechanism
RECORDING SECTION
Carriage drive
mechanism
4–51
1
2
3
4
5
6
