Tf Series Probe Connections - GE Moisture Image Series 1 Startup Manual

April 2004
TF Series Probes (cont.)
1-24
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
If you do connect a probe to the wrong channel, you can either
reconnect the probe to the assigned channel, or reconfigure the
channel (where the probe is connected) as described in Verifying and
Entering Setup Data in Chapter 2 of this manual.
NOTICE FOR BASEEFA CERTIFICATION
The TF Series probe may not be capable of
withstanding the 500 V insulation test required by
clause 5.7 of EN50 020 when installed in the process
media. This must be taken into account in any
installation in which it is used. (See Cert. #
Ex95C2002X in its entirety.) Copies of official
BASEEFA documentation (certificates of compliance,
licenses, etc.) are to be made in their entirety.
Table 1-3: TF Series Probe Connections
Connect:
red wire (moisture H1)
green wire (moisture H2)
white wire (temperature T1)
black wire (temperature T2)
violet wire (IN +)
orange wire (IN –)
yellow wire (OUT +)
blue wire (OUT –)
shield
IMPORTANT: To maintain good contact at each terminal block and
to avoid damaging the pins on the connector, pull the
connector straight off (not at an angle), make cable
connections while the connector is away from the
unit, and push the connector straight on (not at an
angle) when the wiring is complete.
Once you connect the probe(s), perform a calibration test as described
in Performing an MH Calibration Test/Adjustment in Chapter 1 of the
Service Manual, to check for small electrical offsets in the cable.
To STD/TF PROBE TB:
pin #1
pin #2
pin #3
pin #4
pin #5
pin #6
pin #7
pin #8
pin #9
Installation
