set_property PACKAGE_PIN E10 [get_ports FMC1_HPC_GBTCLK1_M2C_C_P]
set_property PACKAGE_PIN F7 [get_ports FMC1_HPC_DP6_M2C_N]
set_property PACKAGE_PIN E9 [get_ports FMC1_HPC_GBTCLK1_M2C_C_N]
set_property PACKAGE_PIN G9 [get_ports FMC1_HPC_GBTCLK0_M2C_C_N]
set_property PACKAGE_PIN G10 [get_ports FMC1_HPC_GBTCLK0_M2C_C_P]
set_property PACKAGE_PIN H4 [get_ports FMC1_HPC_DP5_C2M_P]
set_property PACKAGE_PIN G6 [get_ports FMC1_HPC_DP5_M2C_P]
set_property PACKAGE_PIN H3 [get_ports FMC1_HPC_DP5_C2M_N]
set_property PACKAGE_PIN G5 [get_ports FMC1_HPC_DP5_M2C_N]
set_property PACKAGE_PIN J2 [get_ports FMC1_HPC_DP4_C2M_P]
set_property PACKAGE_PIN H8 [get_ports FMC1_HPC_DP4_M2C_P]
set_property PACKAGE_PIN J1 [get_ports FMC1_HPC_DP4_C2M_N]
set_property PACKAGE_PIN H7 [get_ports FMC1_HPC_DP4_M2C_N]
set_property PACKAGE_PIN B4 [get_ports FMC1_HPC_DP3_C2M_P]
set_property PACKAGE_PIN A6 [get_ports FMC1_HPC_DP3_M2C_P]
set_property PACKAGE_PIN B3 [get_ports FMC1_HPC_DP3_C2M_N]
set_property PACKAGE_PIN A5 [get_ports FMC1_HPC_DP3_M2C_N]
set_property PACKAGE_PIN C2 [get_ports FMC1_HPC_DP2_C2M_P]
set_property PACKAGE_PIN B8 [get_ports FMC1_HPC_DP2_M2C_P]
set_property PACKAGE_PIN C1 [get_ports FMC1_HPC_DP2_C2M_N]
set_property PACKAGE_PIN B7 [get_ports FMC1_HPC_DP2_M2C_N]
set_property PACKAGE_PIN D4 [get_ports FMC1_HPC_DP1_C2M_P]
set_property PACKAGE_PIN C6 [get_ports FMC1_HPC_DP1_M2C_P]
set_property PACKAGE_PIN D3 [get_ports FMC1_HPC_DP1_C2M_N]
set_property PACKAGE_PIN C5 [get_ports FMC1_HPC_DP1_M2C_N]
set_property PACKAGE_PIN E2 [get_ports FMC1_HPC_DP0_C2M_P]
set_property PACKAGE_PIN D8 [get_ports FMC1_HPC_DP0_M2C_P]
set_property PACKAGE_PIN E1 [get_ports FMC1_HPC_DP0_C2M_N]
set_property PACKAGE_PIN D7 [get_ports FMC1_HPC_DP0_M2C_N]
