Installation and Setup Guide
FIELD TITLE and DATA ENTRIES
Siren Options
*176
Entry 1: 0 = external siren
1 = self-activated external siren
Entry 2: 0 = disable siren delay
1 = external siren delay and dialer
delay during entry delay period
when armed AWAY
2 = external siren and dialer delayed
15 seconds when armed STAY
mode
Device Duration 1, 2
*177
Duration 1 – Device Action 5 Timer
0 = 15 secs
1 = 30 secs
2 = 45 secs
3 = 60 secs
4 = 90 secs
5 = 2 min
Duration 2 – Device Action 6 Timer
1 – 7 = 1 to 7 days
*178 RF Supervision / RF Jam Option
0 = RF supervision and RF jam detection
reporting
1 = Report RF supervision failure as tamper
alarm when armed
2 = Report RF Jam as tamper alarm when
armed
3 = Report RF Jam and RF supervision failure
as tamper alarm when armed
NOTES: RF Jam must be enabled in field *22
in order for any RF reporting to be enabled in
this field.
Alarm restore reports must be enabled (field
*70) in order for RF Supervision/RF Jam
alarm restores to be reported.
Trouble reports and trouble restore reports
must be enabled (fields *60, *71) in order for
RF supervision/RF jam trouble conditions and
restores to be reported.
4-16
6 = 2-1/2 min #+12 = 8 min
7 = 3 min #+13 = 10 min
8 = 4 min #+14 = 12 min
9 = 5 min #+15 = 15 min
#+10 = 6 min
#+11 = 7 min
EXPLANATION
Select desired options.
Entry 1: If entry 1 is not set to an external siren
(option 0 or 1), then the second entry is ignored.
Entry 2: Option 1 – When entry delay is active (ex.
reentering premises while armed AWAY) and an
instant zone is faulted, the external siren is delayed
30 seconds and the dialer report is delayed 30
seconds, unless field *50 is set for a greater delay
(the 30-second dialer delay supersedes values less
than 30 seconds set in field *50).
Option 2 – When armed STAY and an instant zone
is faulted, the external siren and dialer are delayed
15 seconds (keypad sounds immediately).
These entries set the duration for output action
options 5 (duration 1) and 6 (duration 2)
programmed in ∗80 Output Function Programming.
Duration 2 can be used as a strobe timer.
Select desired option. See field *22 for related options.
Entry 0: RF jam conditions report as Trouble zone 90
(Contact ID code 344, RF Rcvr Jam Detect)
plus a zone trouble report for each RF zone
in the system (CID code 383, Trouble Sensor
Tamper) when the system is armed or
disarmed. Keypads display Tamper zz (zz =
zones) and Tamper 90 (fixed-word) or
RECEIVER JAM (alpha).
RF supervision failures report as zone
troubles (CID code 381, RF Sensor Super.)
when the system is armed or disarmed.
Keypads display CHECK zz (zz = zone).
Entry 1: Same as entry 0 except RF supervision
failures report as zone alarms (CID code
144, Alarm Sensor Tamper) when the
system is armed; keypads display ALARM
zz.
Entry 2: Same as entry 0 except RF jam conditions
report as zone alarms (Contact ID code 144,
Alarm Sensor Tamper) when the system is
armed; keypads display ALARM zz.
Entry 3: Same as entry 0 when disarmed, but when
system armed, both RF jam conditions and
RF supervision failures report as zones
alarms (Contact ID code 144, Alarm Sensor
Tamper)
