For Vigor2930N - Draytek Vigor2930 Series User Manual

1 . 2 . 2 F o r V i g
1 . 2 . 2 F o r V i g
LED
ACT (Activity)
DoS
CSM
WLAN
WAN1/2
MGMT
VPN
QoS
LED on Connector
WAN 1/2
LAN 1/2/3/4
Interface
Factory Reset
Restart
Phone (1/2)
WAN (1/2)
4
o r 2 9 3 0 n
o r 2 9 3 0 n
Status
Blinking
Off
On
Blinking
On
On
Blinking
On
Blinking
On
Blinking
On
On
Left LED On
(Green)
Off
Blinking
Right LED On
(Green)
Off
Left LED On
(Green)
Off
Blinking
Right LED On
(Green)
Off
Description
Press "Factory Reset" button once to make network connection through WPS.
Press "Factory Reset" button twice to enable or disable WLAN function.
Press "Factory Reset" button for 5 seconds to do the factory reset.
Restore the default settings. Usage: Turn on the router (ACT LED is blinking).
Press the hole and keep for more than 5 seconds. When you see the ACT LED
begins to blink rapidly than usual, release the button. Then the router will restart
with the factory default configuration.
Restart the router forcefully.
Connecters for PSTN phones.
Connecters for remote networked devices.
Explanation
The router is powered on and running normally.
The router is powered off.
The DoS/DDoS function is active.
It will blink while deleting an attack.
The profile of CSM (Content Security
Management) for IM/P2P application is active. (It
is enabled from CSM >> IM/P2P Profile).
Wireless access point is ready.
It will blink while wireless traffic goes through.
It will blink fast when WPS is working and it will
return to normal condition after two minutes.
(You need to setup WPS within 2 minutes.)
The WAN1 or WAN2 port is connected.
It will blink while transmitting data.
The router is managed (handled) by Telnet.
It will blink while being managed by IE browser.
The VPN tunnel is active.
The QoS function is active.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 100Mbps.
The port is disconnected with 10Mbps.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 100Mbps.
The port is disconnected with 10Mbps.
