4. Pull the brake lever to release the lock of the
brake lever.
► Fig.52: 1. Brake lever
5.
Hold the handles firmly with both hands.
► Fig.53
6. Pull the switch trigger.
► Fig.54: 1. Switch trigger
Loading objects
CAUTION:
Before loading objects on the
machine, make sure that the machine is turned off
and the brake lever is locked.
CAUTION:
Before loading objects on the
machine, make sure that the dump unit is locked.
CAUTION:
Be sure to load objects within the
carrier, bucket, or flat bucket. If objects are sticking
out of the carrier, bucket, or flat bucket, they may fall
or collapse if they touch obstacles.
► Fig.55
CAUTION:
Be sure to load objects so that
they are below eye level. If the load is too high, it is
dangerous because the view is obscured. Also, there
is a risk of overturning and injury because the load is
likely to be unbalanced.
► Fig.56
CAUTION:
Do not load the objects beyond
the height of the bucket or flat bucket. Loading the
objects beyond the height of the bucket or flat bucket
may cause the load to fall or collapse.
When loading objects on the carrier, secure the objects
with ropes and tie them down to the rope hooks of the
carrier.
► Fig.57: 1. Rope hook

Dumping objects

CAUTION:
Before lifting the carrier or bucket,
be sure to lock the brake lever.
CAUTION:
Lift the carrier or bucket on flat
and stable ground. Operation on unstable ground
may cause an accident or injury.
CAUTION:
Keep the load to a minimum. If
the load is large, do not try to lift the carrier or
bucket. Reduce the load, and then lift the carrier
or bucket.
CAUTION:
When lifting or returning the car-
rier or bucket, never insert or place a part of your
body between the dump unit and the carrier or
bucket.
CAUTION:
If the load is fixed by ropes or
other means, untie the load before lifting the
dump unit.
CAUTION:
Before lifting the carrier or bucket,
make sure that there are no people or obstacles
around the machine.
You can dump the objects by lifting and tilting the carrier
or bucket.
1.
Stop the machine, and then lock the brake lever.
NOTICE:
It is recommended to chock the front
wheels to stabilize the machine.
2.
Rotate the lock lever of dump unit toward the front
of machine to unlock the dump unit.
► Fig.58: 1. Lock lever
3. Stand at the side of the machine, then hold the
handle of the machine with one hand, and then hold the
handle of the dump unit with the other hand.
► Fig.59
CAUTION:
Hold the handles of the machine
and dump unit firmly, and work in a stable
posture.
4. Tilt the carrier or bucket by lifting up the handle of
the dump unit.
5. Return the carrier or bucket, and then lock the
dump unit by pulling down the handle of the dump unit.
CAUTION:
After dumping loads, be sure to
lock the dump unit by returning the dump unit to
its original position.
Draining liquid
CAUTION:
Before draining the liquid, be sure
to lock the brake lever.
To drain the liquid inside of the flat bucket, loosen and
remove the cap of the flat bucket. Tighten the cap after
the draining.
► Fig.60: 1. Cap
NOTE: When removing the cap, be careful as the
cap may be pushed out by the pressure of liquid. Be
careful not to get the liquid on your face or other parts
of your body.

MAINTENANCE

CAUTION:
Always be sure to park the
machine on flat ground and lock the brake lever
before storage or attempting to perform inspec-
tions or maintenance.
CAUTION:
Always be sure that the lock
key and battery cartridge are removed from
the machine before storage, inspections, or
maintenance.
CAUTION:
Always remove the lock key when
the machine is not in use. Store the lock key in a
safe place out of reach of children.
