Level l Programming - 764 Control with 293 Valve, 3 Cycle Filter

Screen
SU MO TU WE TH FR SA DAYS
Time/Day
Backwash Time
Backwash Length
Capacity
SU MO TU WE TH FR SA DAYS
Time/Day
PM
Backwash Time
Backwash Length
Capacity
SU MO TU WE TH FR SA DAYS
Time/Day
Backwash Time
Backwash Length
Capacity
SU MO TU WE TH FR SA DAYS
Time/Day
Backwash Time
Backwash Length
Capacity
SU MO TU WE TH FR SA DAYS
Time/Day
Backwash Time
Backwash Length
Capacity
SU MO TU WE TH FR SA DAYS
Time/Day
Backwash Time
Backwash Length
Capacity
3
Lbs/ft
SU MO TU WE TH FR SA DAYS
Time/Day
Backwash Time
Backwash Length
Capacity
100
X
Control programming is complete
Note: If one of the following conditions occur:
– control displays Err3 and goes to home position or
– power outage discharges the supercapacitor and when power is restored the time of day is reset;
the Regen Icon will begin flashing. This indicates that a delayed regeneration will occur at the next programmed time of
regeneration. If a delayed regeneration is not desired, press the REGEN Button to disable the delayed regeneration and
the system will regenerate by water usage.
Buttons to
Press
then
or
press
press
then
or
press
press
then
or
press
press
then
or
press
press
then
or
press
press
then
or
press
press
to override
press
or
then
press
Description
1. Program Type
Select "F"
2. Time of Day (12 hr.)
Set to time of day
Note: Setting includes PM indicator.
3. Day of Week
Set to actual day of the week
4. Time of Backwash
Set to desired time of Backwash
Note: Time of Backwash is not used for Alternating mode.
5. Days Override
Leave at 0 to disable
or
Set to desired days between
regeneration
6. Backwash Length (minutes)
Set to desired Backwash length
7. Capacity (gallons)
Set to desired Capacity in
multiples of 100 gallons
29
Range
Days:0
to
99
Minutes: 0
to
200
1
Gallons:
to
900
