Placing Water Conditioning System Into Operation

After you have performed the installation steps, the
conditioner will need to be placed into operation.
Follow these steps carefully, (pages 26 to 31) as they
differ from previous Autotrol valve instructions.
Note: All Logix 764 controls will be shipped in the service
(treated water) position. Check to see that the camshaft
is aligned to service position. See Figure 7 on page 8 for
proper control/camshaft alignment.
The incoming supply water should be turned off.
Remove air from tank(s).
1. Position the bypass valve(s) to the in service (not in
bypass) position.
2. Open the nearest water faucet completely.
3. Open the incoming water supply valve slowly to the
Table 1 Preprogrammed Valves
Type
255 A 255
273 A 273
278 A 278
293 A 293
298 A 298
255 P 255
273 P 273
278 P 278
293 P 293
298 P 298
255 L 255
273 L 273
278 L 278
293 L 293
298 L 298
For the next steps you may want to remove the cover to
watch the camshaft movement.
7. Press to enter the valve type and the proper
preprogrammed valves for your application:
293A for Twin Alternating Filter
298A for Twin Alternating Conditioner
293P for Twin Parallel Filter
298P for Twin Parallel Conditioner
293L for single or multiple tank filters with regener-
ation lockout or remote regeneration start
298L for single or multiple tank conditioners with
regeneration lockout or remote regeneration
start
Valve
Twin Alternating
Twin Parallel
Single Tank Remote Regeneration or
Multi-Single Tank Lockout
quarter open position.
Note: Do not plug in the power supply until step 5. The
tank(s) will fill with water. The air will exit through the
faucet. When water flows steady from the faucet, the
tank(s) are purged.
4. Turn off the faucet then turn off the incoming water
supply.
Power-up the Control
5. Plug the AC adapter into a non-switched outlet. The
display will show the valve type that was loaded from
memory.
If this is the first time the control is powered up the
display will show 255A.
6. Use the or
through the available selections, Table 1.
8-cycle conditioner
3-cycle filter
5-cycle conditioner
3-cycle filter
5-cycle conditioner
8-cycle conditioner
3-cycle filter
5-cycle conditioner
3-cycle filter
5-cycle conditioner
8-cycle conditioner
3-cycle filter
5-cycle conditioner
3-cycle filter
5-cycle conditioner
Note: The control overlay changes depending on
whether a filter or conditioner Logix control was
purchased. If a filter control is programmed to be a
conditioner then the overlay will not be correct. However,
the Logix control will function properly. See previous page
for overlay text.
8. The display will show
"F" for filter set-up. If a number or an "F" is displayed
then the resin volume or filter type has been
preprogrammed, Table 2.
Finish programming the Logix 764 control using the
Level I programming guide.
26
buttons to increment
Connection -
inches
3/4
1
1
2
2
3/4
1
1
2
2
3/4
1
1
2
2
--- . Select media volume or
