Camshaft and Pilot Valve Assembly

1
2
5
6
Table 14Assembly Parts
Item
Part Number
Number
1 1005953
2 1000589
3* 1001751
1267726
4 1000339
5 1006093
6 1000391
7 1000328
8 1005953
* Single tank camshaft allows the unit to go into
Service during Refill.
2
3
4
8
7
Logix Multi Tank Camshaft, "A", "P", or "L" Types
Logix Single Tank Magnum Camshaft, "L" Types
Screw Short, Top Plate
Screw Long, Top Plate
Description
Screw, Pillow Block
Pillow Block
Top Plate
Brine Valve Disc
Pilot Valve Disc
