Magnum IT Dimensional Specifications

2-Inch Inlet and Outlet, 1 1/2-Inch Drain
1-11/16
(4.3 cm)
11-3/4
(29.9 cm)
13-1/2
(34.2 cm)
9
(22.9 cm)
7
(17.8 cm)
9-3/4
(24.8 cm)
16-1/4
(41.3 cm)
4-1/2
(11.4 cm) (11.4 cm)
4-7/16
(11.3 cm)
13-15/16
(35.5 cm)
1-1/16
(2.7 cm)
15
2-15/16
(7.5 cm)
6-1/2
(16.5 cm)
4-1/2
26-11/16
(67.8 cm)
15-7/16
(39.2 cm)
7-1/2
(19 cm)
4-7/16
(11.3 cm)
