KEYLESS ENTRY SYSTEM (IF EQUIPPED)

The keyless entry system uses radio wave. When the button on the transmitter is pressed, a signal is transmitted
in the form of radio wave to the receiver. Then the signal causes the door lock controller to lock and unlock the door.
The door locks can not operated with the transmitter when either of the following conditions applies.
D For 2 seconds after the ignition switch is turned from ON to OFF position.
D The ignition switch is at ON or START position.
D Any door is open.
KEYLESS ENTRY SYSTEM (IF EQUIPPED)
Condition
The power door lock function
is available but the keyless
entry function is not.
Only one power door lock
does not operate.
Operation distance unstable.
NOTE:
D The operation distance of this system varies depending on the position where the transmitter is oper-
ated, at the front side, the rear side or the lateral side. The distance can be affected by radio noises from
a TV station, a power plant, a broadcasting station and so forth.
TYPE 1
DIAGNOSIS
Possible Cause
D Fuse blown
D Code registration error
D Transmitter battery dead
D Wiring or grounding faulty
D Receiver faulty
D Transmitter faulty
D Wiring or coupler faulty
D Actuator (door lock motor) faulty
D Transmitter battery dead
D Transmitter faulty
ON-VEHICLE SERVICE
TYPE 2 ENGINE COOLANT TEMP. (ECT) METER AND
SENSOR
ECT SENSOR
INSPECTION
1) Warm up ECT sensor (1) observing resistance between sensor
terminal (2) and sensor unit (1). Resistance should be de-
creased with increase of its temperature.
2) Check resistance between sensor terminal (2) and sensor unit
(1). If check result is not as specified below, replace sensor.
Replace fuse to check for short.
Register code.
Replace battery.
Repair as necessary.
Replace.
Replace.
Repair as necessary
Replace.
Replace battery.
Replace.
Temperature
50_C (122_F)
BODY ELECTRICAL SYSTEM 8-3
Correction
Resistance
136 – 216 Ω
