Application program
Operating data recording/1
2.2
Circuit diagram
© 2006 ABB STOTZ-KONTAKT GmbH
Device technology
Max. number of
communication objects
250
Table 2:
Application program
Note:
ETS is required for programming. If ETS3 is used a ".VD3" type
file must be imported. The application program is available in
the ETS under ABB/Safety and Monitoring/Controller.
2CDC 072 053 F0006
Fig. 2:
Circuit diagram
1 Label carrier
2 Programming button
3 Programming LED
4 Bus connection terminal
Max. number of
group addresses
254
Max. number of
associations
255
7
