Safety devices

Discharge flap S [A]
Contact with the cutting blade and items
flung out
ÂRisk of injury
¾ Only operate the device with a discharge
flap attached and lowered.
Safety locking system
The safety locking system will only allow the engine
to start when
- the driver is sitting on the seat,
- the brake pedal has been depressed or the park-
ing brake is in the park position,
- the cutter deck has been switched off; i.e.: PTO
switch set to "O/Aus/Off" (PTO = Power-Take-Off).
The safety locking system automatically switches
the cutter deck (PTO) off as soon as the operator
leaves the seat with the PTO activated, irrespective
of whether the parking brake was actuated
beforehand.
The safety locking system automatically switches
the engine off as soon as the operator leaves the
seat without actuating the parking brake beforehand.
In devices without an OCR function or with a
deactivated OCR function, the safety locking
system prevents reversing with the cutting
mechanism activated (automatic shutdown of the
cutting mechanism).
Prior to reversing, switch off the cutting mecha-
Î
nism using the PTO switch.
Note on the PTO switch
In the case of automatic shutdown through
the safety locking system (e.g. reversing or
leaving the seat with the cutting mechanism
activated), first switch the switch off, and
then back on again, to release the clutch
lock (PTO).
Directional references
Directional references on the device (e.g. left, right,
etc.) always refer to when facing forwards.
14
CAUTION !

Assembly

Note
To be able to move the device manually, the
gear release lever must be in the appropri-
ate position. Refer to the section "Operation
– Pushing the mower".
Fitting the steering column Bb
Bottom part [A] of the steering column
Note
Only for devices where the bottom steering
column has been folded down for transport.
Press the bottom part of the steering column for-
Î
wards out of the transport position 1 .
Fix it using the two screws and washers sup-
Î
plied 2 .
Upper part [B] of the steering column
Release the clamping lever in an anti-clockwise
Î
direction 3 .
Tip the steering column forwards into the required
Î
position 4 .
Tighten the clamping lever in a clockwise direc-
Î
tion 3 to lock the steering column in this position.
Installing the steering wheel Bc
Remove cover cap [1] ([A] or [B] depending on
Î
model) from the steering wheel.
Remove screw [2] and the washer [3].
Î
Bring the wheels into a straight position.
Î
Place the steering wheel on the steering shaft.
Î
Put on washer [3] with curved side face up.
Î
Fix the steering wheel using the screw [2].
Î
Insert the cover cap [1] ([A] or [B] depending on
Î
model).
Attaching the discharge flap on the cutter
deck Cb
Remove the screws [1] and nuts [2] on the dis-
Î
charge opening of the cutter deck.
Fix the discharge flap [3] to the discharge opening
Î
using the screws [1] and nuts [2].
