Summary of Contents for Blomberg WAF 1200
- Page 1 Automatic Washing Machine WAF 800 A WAF 1200 A WAF 1220 A Operating instructions...
- Page 2 Deutsch - ab Seite 1 English - from Page 26...
-
Page 3: Table Of Contents
Read this first! Dear customer, By purchasing this appliance you have de- cided in favour of the latest in washing technology – premium quality, long serv- ice live, high reliability and optimal ease of use. • At first, please check if the appliance was received undamaged. -
Page 4: Machine Overview
Machine overview Detergent dispensing drawer Control panel Loading door with door opener Service door with foreign matter trap Height-adjustable feet Drain hose Power cable Transit bars 9a Water supply hose with "Aquasafe+"-protection Water supply hose with "Aquasafe"-protection (alternative to 9a) Accessories (in accessory bag): Holder for drain hose five caps for rear wall opening... -
Page 5: Overview Of Additional Functions
12 Spin speed indicator 13 Programme selector 14 Programme progress indicator 15 Time delay 16 Indicator lamps Overview of additional functions Option In case of leakages, the water sup- Aquasafe ply is mechanically blocked. In case of leakages, the water sup- Aquasafe+ ply is electrically blocked. -
Page 6: Safety First
Safety first Please observe the following information, as otherwise there will be risk of personal injury or material damage and any warran- ty and liability is invalidated. Intended use • This appliance shall only be used for washing, rinsing and spinning textiles that are marked accordingly. -
Page 7: Disposal
Disposal Where to dispose of the packag- ing? Packaging material can be dangerous to children. Keep the packaging mate- rial out of reach of children, or dispose it of according to instructions. The packing is made of materials which can be recycled. •... -
Page 8: The Right Location Of Installation
3. Place the five covers (from the acces- sories bag) onto the openings in the rear panel and use a suitable tool (such as the handle of a screw driver) to push them into place. The smaller cover is intended for the top-mot opening. -
Page 9: Connecting The Water Drain
1. If not already attached, manually screw the bent end of the supply hose tightly onto the rear panel of the ma- chine (not in case of Aquasafe+). 2. Screw the Aquasafe or Aquasafe+ (de- pending on the model) at the end of the supply hose tightly onto the water tap by hand. -
Page 10: Electrical Connection
Fastening the hose holder: 1. Pull the holder included in delivery over the end of the hose. 2. Hand the drain hose with the holder over the edge of the basin or tub and secure it from sliding off – e.g. by fas- tening it with a chain around the wa- ter tap. -
Page 11: Preparing To Wash
After completion of the programme cycle: If the >Door< indicator lamp is glow- ing, the loading door can be opened (see "indicator lamp“). Preparing to wash Sorting the laundry • Sort the laundry by type of fabric, col- our, degree of soiling and permissible water temperature. -
Page 12: The Right Load Capacity
wash. Make sure to follow the instruc- tions on the package. • Wash jeans and delicates inside out. • Keep laundry items made of Angora- wool in the freezer compartment for a few hours before washing – this reduc- es number of fluff balls formed. The right load capacity •... -
Page 13: Detergent Quantity
• Use regular detergent for cottons (60 - 95 °C), otherwise use special detegent for coloured and delicate wash. • Wash woollens only with a special de- tergent for woollens. • Detergents using a modular system al- low you to add bleach and softener in- dividually. -
Page 14: Washing Programmes
Washing programmes The programme selector The programme selector 13 can be rotated clockwise or anticlockwise. You will find an overview of the pro- grammes 13a to 13k in the "Programme table". The programme is selected with the programme selector; however, it starts only when you press the >Start/ Pause<... -
Page 15: Options
Options The buttons Depending on the programme specif- ic additional functions 18a to 18f can be activated by pressing a button. • Press the required buttons before starting the programme. • Meaningless combination of buttons cannot be selected together. Example: >Intensive<... -
Page 16: Spin Speed Selector
To activate the Child-proof lock: • Press both buttons shown above at the same time and hold for approx. 2 seconds until the >Child-proof lock< 16a indicator lamp starts glowing. Spin speed selector The appropriate maximum spin speed is automatically set in each pro- gramme. -
Page 17: Progress Of Programme
Changing the delay time If you want to change the time during the countdown: 1. Press the >Start/Pause< button. 2. Use the >Time delay< 15 button to set the desired time delay. 3. Push the >Start/Pause< button. The time delay countdown phase begins. Progress of programme This row of indicator lamps shows the progress of the currently running pro-... -
Page 18: Indicator Lamps
Indicator lamps The indicator lamps 16a to 16d signal im- portant states of the machine to you. >Child-proof lock< The indicator lamp 16a glows when the Child-proof lock is activated. • See "Child-proof lock" for information on deactivating the Child-proof lock. >No water intake<... - Page 19 Programme is in rinse and hold You can see this from the blinking of the >Rinse hold< indicator lamp and the >Start/Pause< button. If you now want to spin: 1. Set spin speed. 2. Press the >Start/Pause< button. The programme continues, pumps out the water and spins.
-
Page 20: Programme Table
Programme table Hot wash/Coloured Durable fabrics made of cotton and linen Hygiene + 90°C: cotton with high demands for hygiene Active 40 °C: cotton (energy saving-programme) Mini 30: Cotton, blended fabric (short programme) Easy-care Synthetics (polyester, polya- mide) and blended fabrics (with cotton) Delicates Delicates (rayon, silk, etc.) - Page 21 Hot wash/Coloured Standard programme Hygiene +90°C Active 40 °C Mini 30 Easy-care Standard programme Delicates Standard programme Woollens Standard programme Hand wash Standard programme Special programmes Rinse Spin Drain The actual number of programme steps can deviate from the specifications listed above depending upon the function (e.g.
-
Page 22: Cleaning And Care
Cleaning and care Detergent dispensing drawer Clean when necessary: 1. Open the drawer as far as possible. 2. Push down the depression on the suc- tion cup and pull the drawer out com- pletely. 3. Clean the drawer under warm running water. - Page 23 Rust stains may occur due to foreign objects made of metal. In such cases: Clean the drum with a stainless steel cleaning agent. Never use steel wool or scrub sponges. Housing and control panel When necessary: • Clean cabinet with soap suds or a mild cleaner;...
- Page 24 4. Clean foreign object trap and the pump opening. Check if the pump im- peller (in the pump opening) can be turned freely. 5. Replace the cap on the drain hose and put it away. 6. Replace the foreign object trap and turn it tight (in clockwise direction).
-
Page 25: Troubleshooting
Troubleshooting If you experience this … Appliance cannot be switched on or programme will not start Machine won't react to input >No water intake< indicator lamp is glowing Detergent or fabric conditioner are not properly washed in Softener compartment (middle compartment in the detergent dispensing drawer) is full of water at end of programme... -
Page 26: Tips For Removing Stains
If you experience this … Appliance vibrates heavily when spinning Door will not open Power failure during washing Residual matter on laundry Let us help you! If you can not solve the problem yourself, contact our customer service. Specify the Tips for removing stains Type of stain Grease... -
Page 27: Technical Specifications And Consumption Data
Technical specifications and consumption data Load capacity (dry weight) – Hot wash/Coloured, Hygiene +, Active 40 °C – Easy-care – Mini 30 – Delicates – Woollens, Hand wash Spin speeds – Hot wash/Coloured – Easy-care – Delicates, Woollens, Hand wash Dimensions –...
