NCK alarms
Program Clear alarm with NC START or RESET key and continue the program.
Continuation:
10961 [Channel %1: ] Block %2 maximum cubic polynomials are allowed on active radius
compensation.
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: With active radius compensation, only up to cubic polynomials are permissible for the geometry axes. In this case no
4th or 5th degree polynomials can be programmed.
Reaction: Correction block is reorganized.
Local alarm reaction.
Interface signals are set.
Alarm display.
NC Stop on alarm at block end.
Remedy: Modify part program.
Program Clear alarm with NC START or RESET key and continue the program.
Continuation:
10980 [Channel %1: ] Block %2 orientation smoothing not possible
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: This alarm can have the following causes:
1. Orientation smoothing cannot be activated with active path-relative orientation interpolation with ORIPATH.
This means that in the 34th modal G code group
the G code OSOF must be active.
2. The path-relative orientation interpolation cannot be activated with ORIPATH and ORIPATH_MODE = 1
because MD28580 $MC_MM_ORIPATH_CONFIG = 0. This MD must have the value 1.
3. Smoothing of the orientation cannot be activated with OSD or OST
because MD28580 $MC_MM_ORIPATH_CONFIG = 0. This MD must have the value 1.
Reaction: Correction block is reorganized.
Interpreter stop
Interface signals are set.
Alarm display.
Remedy: Modify part program.
Program Clear alarm with NC START or RESET key and continue the program.
Continuation:
10982 [Channel %1: ] Block %2 orientation smoothing not possible with ORISON
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: This alarm has the following cause:
The smoothing of the orientation with ORISON is only possible if MD
MD28590 $MC_MM_ORISON_BLOCKS >= 4.
Reaction: Correction block is reorganized.
Interpreter stop
Interface signals are set.
Alarm display.
Remedy: Modify part program or set MD28590 $MC_MM_ORISON_BLOCKS >= 3.
Program Clear alarm with NC START or RESET key and continue the program.
Continuation:
104
Diagnostics Manual, 07/2010, 6FC5398-8BP40-0BA0
Alarms
